DP010402NPW01, DP010506NPW01, DP020402NPW01,

DP020402NPW01, Rolled Steel NEMA Premium Efficiency 20Hp 2P 254/6T 3Ph 230/460//190-220/380-415 V 60 Hz IC01 - ODP - Foot-mounted

E-Motor Nations

$1,795.74

Category	Specification/Feature
Power	20 HP (15 kW)
Voltage	230/460 V, 60 Hz
Poles	2
Speed	3600 rpm
Torque	29.8 ft.lb (Rated), 180% (Locked Rotor), 240% (Breakdown)
Current	47.6/23.8 A (Rated), 286/143 A (Locked Rotor)
Mounting	Foot-mounted (F-1)
Frame	254/6T, Rolled Steel
Enclosure	Without Fan Cover, Without Fan
Insulation	Class F, 80 K Temp Rise
Bearings	6309 Z C3 (DE), 6208 Z C3 (NDE)
Rotation	CW and CCW
Overload	Without overload protector
Grease	Mobil Polyrex EM
LRC	6.0x (Code G)
Noise Level	70.0 dB(A)
Service Factor	1.15
Sealing	Without Bearing Seal
Flange	Without Flange
