HT000404NPW01, HT000504NPW01, HT000406NPW01, HT000506NPW01, HT001402NPW01, HT001502NPW01, HT001404NPW01, HT001504NPW01, HT002402NPW01, HT002502NPW01, HT002404NPW01, HT002504NPW01,

HT002502NPW01, ELECTRIC MOTOR THREE PHASE 2Hp 3520 Rpm 2P 143/5T 575 C/W 6 leads WCF2 60Hz F-1/B3R(D) IP55 NEMA PREMIUM EFFICIENCY ROLLED STEEL IHP

E-Motor Nations

$570.06

Category	Specification/Feature
Power	2 HP (1.5 kW)
Voltage	575 V, 60 Hz
Poles	2
Speed	3600 rpm
Torque	2.98 ft.lb (Rated), 250% (Locked Rotor), 300% (Breakdown)
Current	1.98 A (Rated), 19.6 A (Locked Rotor), 0.850 A (No Load)
Mounting	F-1/B3R(D)
Frame	143/5T, Rolled Steel
Enclosure	TEFC
Insulation	Class F, 80 K Temp Rise
Bearings	6205 ZZ (DE), 6203 ZZ (NDE)
Rotation	Both (CW and CCW)
Overload	Without Overload Protector
Grease	Mobil Polyrex EM
Noise Level	68.0 dB(A)
Service Factor	1.15
Sealing	V'Ring
Flange	Without
Degree of Protection	IP55
