CP007404NPW01, CP010502NPW01, CP010404NPW01, CP010504NPW01, CP015502NPW01, CP015404NPW01, CP015504NPW01, CP020402NPW01, CP020502NPW01, CP020404NPW01, CP020504NPW01, CP025502NPW01,

CP010404NPW01, Rolled Steel NEMA Premium Efficiency 10Hp 1770 Rpm 4P 213/5TC 3Ph 230/460//190-220/380-415 V 60 Hz IC01 - ODP - Foot-mounted

E-Motor Nations

$1,227.70

Category	Specification/Feature
Power	10 HP (7.5 kW)
Voltage	230/460 V, 60 Hz
Poles	4
Speed	1800 rpm
Torque	29.7 ft.lb (Rated), 250% (Locked Rotor), 350% (Breakdown)
Current	24.8/12.4 A (Rated), 174/86.8 A (Locked Rotor)
Mounting	Foot-mounted (F-1)
Frame	213/5TC, Rolled Steel
Enclosure	Without Fan Cover, Without Fan
Insulation	Class F, 80 K Temp Rise
Bearings	6208 ZZ (DE), 6206 ZZ (NDE)
Rotation	CW and CCW
Overload	Without overload protector
Grease	Mobil Polyrex EM
Noise Level	59.0 dB(A)
Service Factor	1.15
Sealing	Without Bearing Seal
Flange	C
